A scheme of the alleged Asus Prime X670-P WiFi motherboard for AMD's next-generation Ryzen 7000-series 'Raphael' processors in AM5 packaging reveals basic schematics of the platform and confirms that AMD's X670 chipset uses two identical chips. Meanwhile, this particular motherboard appears to use a PCIe switch to connect two chipsets to the CPU efficiently. However, this may not be the case
AMD 600-series chipsets feature PCIe Gen5, DDR5 support
AMD X670E is the flagship chipset for the new motherboard series.
AMD AM5 infrastructure is based on a new LGA 1718 socket which will natively support CPUs up to 170W. The 600-series platform is equipped for DDR5 memory and PCIe Gen5 for storage and graphics (depending on a chipset).
AMD confirmed that X670E (Extreme) is designed for
