Synopsys, Inc. today announced the industry's first complete IP solution for the PCI Express (PCIe ) 6.0 technology that includes controller, PHY and verification IP, enabling early development of PCIe 6.0 system-on-chip (SoC) designs. Built on Synopsys' widely deployed and silicon-proven DesignWare IP for PCIe 5.0, the new DesignWare IP for PCIe 6.0 supports the latest features in the standard specification including, 64 GT/s PAM-4 signaling, FLIT mode and L0p power state. Synopsys' complete IP solution addresses evolving latency, bandwidth and power-efficiency requirements of high-performance computing, AI and storage SoCs.

To achieve the lowest latency with maximum throughput for all transfer sizes, the DesignWare Controller for PCI Express 6.0 utilizes a MultiStream architecture, delivering up to 2X the performance of a single-stream design. The Controller, with available 1024-bit architecture, allows designers to achieve 64 GT/s x16 bandwidth while closing timing at 1 GHz. In addition, the controller provides optimal flow with multiple data sources and in multi-virtual channel implementations. To facilitate accelerated testbench development with built-in verification plan, sequences and functional coverage, the VC Verification IP for PCIe uses native SystemVerilog/UVM architecture that can be integrated, configured and customized with minimal effort.
